BC817 – (SMD SOT-23 Package) – NPN General Purpose Transistor

BC817 NPN general-purpose transistors comes in Surface-Mounted Device (SMD) plastic packages. It is mainly used in General-purpose switching and amplification.

Specifications:-

• Mounting Style: SMD/SMT
• Package/Case: SOT-23-3
• Transistor Polarity: NPN
• Configuration: Single
• Collector- Emitter Voltage VCEO Max: 45 V
• Collector- Base Voltage VCBO: 50 V
• Emitter- Base Voltage VEBO: 5 V
• Maximum DC Collector Current: 0.5 A
• Gain Bandwidth Product fT: 100 MHz
• Maximum Operating Temperature: + 150 C
• DC Current Gain hFE Max: 250 at 100 mA at 1 V
• DC Collector/Base Gain hFE Min: 250 at 100 mA at 1 V, 40 at 500 mA at 1 V
• Minimum Operating Temperature: – 65 C
• Pd – Power Dissipation: 250 mW
